Novotronic AS-I TPE
Industrial fieldbus cable, TPE
- 2 (2)
- 1.5 (2)
- No (2)
| E-number | Dimension n x mm² | Outer dimensions H x B mm | Weight kg/100m | Colour |
| 4958670 | 2x1,5 | 4,0 x 10,0 | 6 | Black |
| 4958680 | 2x1,5 | 4,0 x 10,0 | 6 | Yellow |
Rated Voltage Uo/U control cores:
300V
Conductor class:
Class 6 = extra fine stranded wires
Conductor material:
Copper
Core insulation:
TPE
Core identification:
Blue and Brown
Outer sheath:
TPE
Bending radius fixed:
min 24mm
Min operating temperature fixed:
-40°C
Max operating temperature fixed:
+105°C
Testing voltage:
1500V Core/Core
Conductor resistance:
max. 13,7 Ohm/km
Halogen-free acc. to:
IEC 60754
Flame retardant:
IEC 60332-1
