Approvals:
UL/CSA AWM
Rated Voltage acc to. UL/CSA:
1000V
Conductor class:
Class 6 = extra fine stranded wires
Conductor material:
Copper
Core insulation:
Polyolefin
Protective conductor:
Yellow/Green
Overall shield:
Braided tinned copper wire
Shield coverage:
≥85%
Outer sheath:
PUR
Sheat colour:
See table
Bending radius fixed:
3 x cable diameter
Bending radius moved:
6 x cable diameter
Min operating temperature fixed:
-50°C
Max operating temperature fixed:
+80°C
Min operating temperature moved:
-40°C
Max operating temperature moved:
+80°C
Oil resistance:
EN 50363-10-2, UL 1581
UV resistant acc. to:
EN 50289-4-17, ASTM-D-2565-16, ISO 4892-2
Halogen-free acc. to:
IEC 60754
Flame retardant:
IEC 60332-1, UL1581 VW1, CSA FT1
