Standard:

IEC 60092-353, IEC 60092-360

Approvals:

ABS, BV, CCS, CRS, DNV, LR, NK, RINA

Rated Voltage Uo/U:

0,6/1kV

Conductor class:

≤10mm² Class 2 = stranded wires / ≥16mm² Class 5 = fine stranded wires

Conductor material:

Copper

Core insulation:

XLPE

Core identification:

HD 308 S2 (1 Core: Black, 2 Cores: Brown, Blue, 3 Cores: Brown, Black, Grey or Green/Yellow, Blue, Brown, 4 Cores: Brown, Black, Grey, Blue or Green/Yellow, Brown, Grey, Black, 5 Cores: Colour coded or Green/Yellow, Brown, Grey, Black, Blue, ≥7 Cores: Colour coded)

Protective conductor:

Yellow/Green

Outer sheath:

Polyolefin

Sheat colour:

Black

Bending radius fixed:

4 x cablediameter at Ø<25mm, 6 x cablediameter at Ø>25mm

Min operating temperature fixed:

-40°C

Max operating temperature fixed:

+90°C

Lowest installation temperature:

-15°C

Conductor resistance:

See technical appendix

Max temperature at conductor:

+90°C

Halogen-free acc. to:

IEC 60754

Smoke emission:

IEC 61034

Flame retardant:

IEC 60332-1, IEC 60332-3-22
