Standard:

IEC 60092/353, IEC 60092/350-351-359

Approvals:

ABS, BV, CRS, DNV, LR, NK, RINA

Rated Voltage Uo/U:

0,6/1kV

Conductor class:

Class 5 = fine stranded wires

Conductor material:

Copper

Core insulation:

XLPE

Core identification:

HD 308 S2 (1 Core: Black, 2 Cores: Brown, Blue, 3 Cores: Brown, Black, Grey or Green/Yellow, Blue, Brown, 4 Cores: Brown, Black, Grey, Blue or Green/Yellow, Brown, Grey, Black, 5 Cores: Colour coded or Green/Yellow, Brown, Grey, Black, Blue, ≥7 Cores: Colour coded)

Outer sheath:

SHF1

Sheat colour:

Black

Bending radius fixed:

6 x cable diameter

Min operating temperature fixed:

-40°C

Max operating temperature fixed:

+90°C

Halogen-free acc. to:

IEC 60754/1-2

Smoke emission:

IEC 61034/1-2 (DIN EN 50268/1-2)

Flame retardant:

IEC 60332-1, IEC 60332-3-22
