PICO-DALILINK

Create product sheet (PDF)
Questions/Order
Material Enclosure:
Polycarbonate, UV-resistant
Temperature range:
-25°C....+55°C
Ingress protection:
IP20
Protection category:
II
Settings:
DALI LINK Bluetooth-app
Light values:
10 - 2500 Lux
Extension of the detection area:
with detector in slave mode
Area of coverage:
circular 360°
Range of coverage:
Ø H 2.50m / T = 18°C:
seated 4m
tangential 10m
radial 6m
Recommended height for mounting:
2,5m
Light measurement:
Mixed light, daylight + artificial light
Follow-up time:
1 - 120min.
Channel 1:
For light control depending on brightness.
Halogen-Free:
Yes

Bruksanvisning 93908_PICO-DALILINK_de_en_fr_sv_V3.pdf
Quick manual DALI LINK sv.PDF
