PD4-M-3C-TRIO
Supply voltage:
110-240VAC / 50-60Hz
Power consumption:
approx. 0,5W
Material Enclosure:
Polycarbonate, UV-resistant
Temperature range:
-25°C....+50°C
Protection category:
II
Settings:
Potentiometers, DIP switches and remote control
Extension of the detection area:
with slave detector
Area of coverage:
circular 360°
Range of coverage:
Ø H 2.50m / T = 18°C:
seated 6.40m
tangential 24m
radial 8m
seated 6.40m
tangential 24m
radial 8m
Recommended height for mounting:
2,5m
Light measurement:
Mixed light, daylight + artificial light
Follow-up time:
1 - 90min.
Channel 1:
Relä för belysningsstyrning NO med pretravel volfram kontakt, ljusreglerad
Belastningsförmåga:
3000 W, cos φ = 1
1500 VA, cos φ = 0,5
800W LED
max. startström Ip (20ms) = 165 A
max. startström lp (200 µs) = 800 A
Potentiometer 10 - 2000 lux
Belastningsförmåga:
3000 W, cos φ = 1
1500 VA, cos φ = 0,5
800W LED
max. startström Ip (20ms) = 165 A
max. startström lp (200 µs) = 800 A
Potentiometer 10 - 2000 lux
Channel 2:
Relä för belysningsstyrning NO med pretravel volfram kontakt, ljusreglerad
Belastningsförmåga:
3000 W, cos φ = 1
1500 VA, cos φ = 0,5
800W LED
max. startström Ip (20ms) = 165 A
max. startström lp (200 µs) = 800 A
Potentiometer 10 - 2000 lux
Belastningsförmåga:
3000 W, cos φ = 1
1500 VA, cos φ = 0,5
800W LED
max. startström Ip (20ms) = 165 A
max. startström lp (200 µs) = 800 A
Potentiometer 10 - 2000 lux
Relay channel 3:
HVAC control potential-free (dry)
max. inrush current Ip (20ms) = 120 A1x dry NO contact
Switching power:
3000 W, cos φ = 1
1500 VA, cos φ = 0.5
300W LED
max. inrush current Ip (20ms) = 120 A1x dry NO contact
Switching power:
3000 W, cos φ = 1
1500 VA, cos φ = 0.5
300W LED
Dimensions:
H x Ø mm: UTP 85 x 124, TAK 100 x 117
Visible portion when built into ceiling:
H x Ø mm: 32 x 117
Push button:
3 push buttons
Halogen-Free:
Yes
